PILZ 680003 4869L4 Compact Safety Relay Module – Real-World Machine Guarding
This little workhorse handles emergency stops and safety gates where space is tight – think packaging lines crammed into old factory corners or robotic cells where every millimeter counts. You’ll find it wired into conveyor guards, press brakes, and those annoyingly cramped injection molding machines where standard relays just won’t fit. Honestly, it’s saved more fingers than I can count; last month a plant in Detroit avoided a major incident when this module cut power to a stamping press during a guard bypass attempt. Not flashy, but gets the job done.
| Brand | PILZ |
| Model | 680003 4869L4 |
| Physical Dimensions | 48mm (W) × 90mm (H) × 75mm (D) – barely wider than a credit card |
| Weight | 200g (light enough to mount vertically without sagging) |
| Voltage Range | 20-253V AC – handles everything from dusty 24V control panels to 240V European lines |
| Switching Capacity | 3A @ 250V AC – sufficient for most solenoid valves and small contactors |
| Response Time | Under 18ms – stops presses before fingers reach the danger zone |
| Operating Temp | -25°C to +70°C – survived a Chicago winter in an unheated warehouse once |
We see these daily in food processing plants where washdowns demand compact, sealed solutions – no room for bulky safety PLCs. Recently replaced a fried relay in a bottling line using this exact model; took 20 minutes including wiring. For similar applications, we regularly move Allen Bradley 440G-V2SA12, Schneider XPS MF480, and Siemens 3SK1101 relays when space isn’t the main issue. Oh, and that brewery in Portland? They’ve got eight of these guarding their canning lines after a near-miss with a palletizer.
Why Maintenance Teams Actually Like This Thing
Forget the marketing fluff – it’s the little things that matter. The test button actually works after five years (unlike some brands that seize up), and the screw terminals grip wires properly without needing re-tightening every six months. Personally, I found the dual-channel monitoring catches sneaky failures better than single-channel relays – caught a stuck contact during routine testing at an automotive plant last quarter. Compatibility’s solid with most Allen Bradley MicroLogix systems and Siemens S7-1200s without extra adapters. Redundancy? Not full safety PLC territory, but dual circuits mean if one channel fails, the other still cuts power. One technician told me, “It’s the relay I keep in my toolbox for emergencies” – high praise in this business. Just don’t expect it to replace a full Triconex system for nuclear applications, obviously.
There are no reviews yet.
